Key specs
Resistance25 µΩ
Tolerance250 m%
Temperature coefficient15 ppm/°C
| Power | |
|---|---|
| Power (Watts) | - |
| Environment and package | |
| Height - Seated (Max) | - |
| Mounting Feature | Flanges |
| Operating Temperature | 30°C ~ 70°C |
| Package / Case | Rectangular Case - Open |
| Size / Dimension | 9.625" L x 4.000" W (244.48mm x 101.60mm) |
| Temperature Coefficient | ±15ppm/°C |
| Other | |
| Coating, Housing Type | - |
| Composition | Metal Element |
| Failure Rate | - |
| Features | Current Sense, Flame Proof, Non-Inductive, Pulse Withstanding, Safety |
| Lead Style | 4-Terminal |
| Manufacturer | Riedon products by Bourns |
| Packaging | Bulk |
| Part Status | Active |
| Resistance | 25 µOhms |
| Series | RSJ |
| Tolerance | ±0.25% |
