MEAN WELL USA Inc.Taiwan, China
AC/DC CONVERTER 48V 45W
All alternatives
View full reportTechnical parameters
Key specs
Input voltage80 ~ 264 V
Output voltage48 V
Output current940 mAMax
Power45 WMax
Outputs1
| Power | |
|---|---|
| Current - Output 1 | 940 mA |
| Power (Watts) | 45W |
| Voltage - Input | 80 ~ 264 VAC |
| Voltage - Isolation | 4 kV |
| Voltage - Output 1 | 48V |
| Voltage - Output 2 | - |
| Voltage - Output 3 | - |
| Voltage - Output 4 | - |
| Voltage - Output 6 | - |
| Environment and package | |
| Mounting Type | Chassis Mount |
| Operating Temperature | -30°C~70°C(WithDerating) |
| Package | Tray |
| Size / Dimension | 3.00" L x 2.00" W x 0.95" H (76.2mm x 50.8mm x 24.0mm) |
| Other | |
| Applications | Medical |
| Approval Agency | CB, CE, cURus, TUV |
| Base Product Number | RPS-45 |
| Efficiency | 91% |
| Features | Adjustable Output |
| Mfr | MEAN WELL USA Inc. |
| Minimum Load Required | No |
| Number of Outputs | 1 |
| Product Status | Active |
| Series | RPS-45 (45W) |
| Type | Open Frame |
