View full reportTechnical parameters
| Power | |
|---|---|
| Current Rating (Amps) | - |
| Power (Watts) | 22.00W |
| Voltage Range | - |
| Voltage - Rated | 230VAC |
| AC and DC characteristics | |
| Noise | 60.0dB(A) |
| Environment and package | |
| Lifetime @ Temp. | - |
| Operating Temperature | - |
| Size / Dimension | Square - 135mm L x 135mm H |
| Other | |
| Air Flow | 31.8 CFM (0.890m³/min) |
| Approval Agency | CE, CSA, UL, VDE |
| Base Product Number | RG90 |
| Bearing Type | Sintec |
| Fan Type | Blower, Flatpak |
| Features | - |
| Ingress Protection | - |
| Manufacturer | ebm-papst Inc. |
| Material - Blade | Plastic, Fiberglass Reinforced |
| Material - Frame | Plastic, Glass Filled |
| Packaging | Box |
| Part Status | Active |
| RPM | - |
| Series | RG90 |
| Static Pressure | - |
| Termination | 2 Wire Leads |
| Weight | 1.3 lbs (589.7 g) |
| Width | 38.00mm |
