E-SwitchUnited States
SWITCH ROCKER DPST 8A 125V
All alternatives
View full reportTechnical parameters
Key specs
CircuitDPST
Switch functionOn-Off
Current rating8 AMax
Voltage rating125 VMax
| Power | |
|---|---|
| Current Rating (Amps) | 8A (AC) |
| Illumination Voltage (Nominal) | - |
| Voltage Rating - AC | 125 V |
| Environment and package | |
| Mounting Type | Panel Mount, Snap-In |
| Operating Temperature | -30°C~85°C |
| Package | Bulk |
| Panel Cutout Dimensions | Rectangular - 19.30mm x 13.00mm |
| Other | |
| Actuator Marking | O - |
| Actuator Type | Concave (Curved) |
| Circuit | DPST |
| Color - Actuator/Cap | White |
| Electrical Life | 10,000 Cycles |
| Features | - |
| Illumination Type, Color | - |
| Ingress Protection | - |
| Mechanical Life | 15,000 Cycles |
| Mfr | E-Switch |
| Product Status | Obsolete |
| Series | RC1083 |
| Switch Function | On-Off |
| Termination Style | Quick Connect - 0.187" (4.7mm) |
Documents
No documents are linked to this part yet.
