OhmiteUnited States
RES SMD 2.7 OHM 5% 1/2W J LEAD
All alternatives
View full reportTechnical parameters
Key specs
Resistance2.7 Ω
Tolerance5 %
Power500 mW
Temperature coefficient400 ppm/°C
| Power | |
|---|---|
| Power (Watts) | 0.5W, 1/2W |
| Environment and package | |
| Height - Seated (Max) | 0.231" (5.87mm) |
| Operating Temperature | -55°C~150°C |
| Package | Bulk |
| Package / Case | 6327 J-Lead |
| Size / Dimension | 0.625" L x 0.273" W (15.88mm x 6.93mm) |
| Supplier Device Package | SMD J-Lead, Recessed |
| Temperature Coefficient | ±400ppm/°C |
| Other | |
| Composition | Carbon Composition |
| Failure Rate | - |
| Features | Pulse Withstanding |
| Mfr | Ohmite |
| Number of Terminations | 2 |
| Product Status | Active |
| Resistance | 2.7 Ohms |
| Series | RC |
| Tolerance | ±5% |
Documents
No documents are linked to this part yet.
