View full reportTechnical parameters
Key specs
Capacitance10 µF
Rated voltage50 V
Tolerance20 %
ESR120 mΩMax
Lifetime4 kh125°C
| Power | |
|---|---|
| Voltage - Rated | 50 V |
| AC and DC characteristics | |
| Ripple Current @ High Frequency | 500 mA @ 100 kHz |
| Ripple Current @ Low Frequency | 50 mA @ 120 Hz |
| Environment and package | |
| Height - Seated (Max) | 0.240" (6.10mm) |
| Lifetime @ Temp. | 4000 Hrs @ 125°C |
| Mounting Type | Surface Mount |
| Operating Temperature | -55°C ~ 125°C |
| Package / Case | Radial, Can - SMD |
| Size / Dimension | 0.197" Dia (5.00mm) |
| Surface Mount Land Size | 0.209" L x 0.209" W (5.30mm x 5.30mm) |
| Other | |
| Applications | Automotive |
| Capacitance | 10 µF |
| ESR (Equivalent Series Resistance) | 120mOhm |
| Features | - |
| Lead Spacing | - |
| Manufacturer | Taiyo Yuden |
| Packaging | Tape & Reel (TR) Cut Tape (CT) Digi-Reel® |
| Part Status | Active |
| Ratings | AEC-Q200 |
| Series | HVK |
| Tolerance | ±20% |
| Type | Hybrid |
