Recom PowerAustria
AC/DC CONVERTER 15V 6W
All alternatives
View full reportTechnical parameters
Key specs
Input voltage80 ~ 264 V
Output voltage15 V
Output current400 mAMax
Power6 WMax
Outputs1
| Power | |
|---|---|
| Current - Output 1 | 400 mA |
| Power (Watts) | 6W |
| Voltage - Input | 80 ~ 264 VAC, 115 ~ 370 VDC |
| Voltage - Isolation | 3 kV |
| Voltage - Output 1 | 15V |
| Voltage - Output 2 | - |
| Voltage - Output 3 | - |
| Voltage - Output 4 | - |
| Voltage - Output 6 | - |
| Environment and package | |
| Mounting Type | Chassis Mount |
| Operating Temperature | -25°C~75°C(WithDerating) |
| Package | Bag |
| Size / Dimension | 2.11" L x 1.09" W x 0.62" H (53.5mm x 27.8mm x 15.7mm) |
| Other | |
| Applications | ITE (Commercial) |
| Approval Agency | CE, cURus |
| Efficiency | 79% |
| Features | DC Input Capable, Universal Input |
| Mfr | Recom Power |
| Minimum Load Required | Yes |
| Number of Outputs | 1 |
| Product Status | Obsolete |
| Series | POWERLINE RAC06-C (6W) |
| Type | Enclosed |
