SWITCH ROTARY 3POS 0.4VA 20V
All alternatives
View full reportTechnical parameters
Key specs
Voltage rating20 VMax
| Power | |
|---|---|
| Current Rating (Amps) | 0.4VA (AC/DC) |
| Voltage Rating - AC | 20 V |
| Voltage Rating - DC | 20 V |
| Environment and package | |
| Mounting Type | Through Hole |
| Package | Bag |
| Panel Cutout Dimensions | - |
| Other | |
| Actuator Length | 9.53mm |
| Actuator Type | Flatted (6.35mm Dia) |
| Angle of Throw | 36° |
| Base Product Number | R10305RN |
| Circuit per Deck | SP3T, Adjacent Contact |
| Contact Finish | Gold |
| Contact Material | Copper |
| Contact Timing | Non-Shorting (BBM) |
| Depth Behind Panel | 10.29mm |
| Features | - |
| Index Stops | Fixed |
| Mfr | C&K |
| Number of Decks | 1 |
| Number of Poles per Deck | 1 |
| Number of Positions | 3 |
| Product Status | Active |
| Series | R |
| Termination Style | PC Pin |
