TDK-LambdaJapan
DC DC CONVERTER 5V 10W
All alternatives
View full reportTechnical parameters
Key specs
Input voltage9 ~ 18 V
Output voltage5 V
Output current2 AMax
Power10 WMax
IsolationIsolated
| Power | |
|---|---|
| Current - Output (Max) | 2A |
| Power (Watts) | 10 W |
| Voltage - Input (Max) | 18V |
| Voltage - Input (Min) | 9V |
| Voltage - Output 1 | 5V |
| Voltage - Output 2 | - |
| Voltage - Output 3 | - |
| Voltage - Output 4 | - |
| Environment and package | |
| Mounting Type | Through Hole |
| Operating Temperature | -40°C ~ 85°C (With Derating) |
| Package / Case | 6-DIP Module |
| Size / Dimension | 1.59" L x 0.87" W x 0.31" H (40.4mm x 22.1mm x 8.0mm) |
| Supplier Device Package | 6-DIP Module |
| Other | |
| Applications | ITE (Commercial) |
| Efficiency | 84% |
| Features | Remote On/Off, OCP |
| Mfr | TDK-Lambda |
| Number of Outputs | 1 |
| Packaging | Bulk |
| Part Status | Obsolete |
| Series | PSS (10W) |
| Type | Isolated Module |
Documents
No documents are linked to this part yet.
