View full reportTechnical parameters
| Environment and package | |
|---|---|
| Conduit Hub Size | - |
| Operating Temperature | -20°C ~ 100°C |
| Panel Hole Size | 0.886" (22.5mm) |
| Thread Size | PG16 |
| Other | |
| Color | Black |
| Includes | Locknut |
| Ingress Protection | IP68 - Dust Tight, Waterproof |
| Manufacturer | SAB North America |
| Material | Polyamide (PA6), Nylon 6 |
| Outside Cable Diameter (Max) | 0.394" (10.00mm) |
| Outside Cable Diameter (Min) | 0.197" (5.00mm) |
| Packaging | Bulk |
| Part Status | Active |
| Series | CG 100 PG |
| Thread Length | 0.394" (10.00mm) |
| Type | Cable Gland |
