View full reportTechnical parameters
| Power | |
|---|---|
| Current - Output | 275 mA |
| Power (Watts) - Per Port | 15.4W |
| Voltage - Input | 90 ~ 264 VAC |
| Voltage - Output | 56V |
| Environment and package | |
| Mounting Type | Desktop |
| Operating Temperature | -20°C~50°C |
| Package | Box |
| Size / Dimension | 4.18" L x 1.56" W x 1.07" H (106.2mm x 39.5mm x 27.3mm) |
| Other | |
| Approval Agency | cULus, IEC |
| Base Product Number | POE15M |
| Compliance | IEEE802.3af |
| Data Rate | - |
| Efficiency | - |
| Features | OCP, OVP, SCP |
| Input Connector | IEC 320-C6 (Power), RJ45 (Data) |
| Mfr | Phihong USA |
| Number of Ports | 1 |
| Output Connector | RJ45 (Data, Power) |
| Product Status | Discontinued at Digi-Key |
| Series | POE15M |
| Standard Number | 60950-1 |
| Type | Passive Injector |
