View full reportTechnical parameters
| Power | |
|---|---|
| Current Rating (Amps) | 2 A |
| Voltage - Rated | 16VDC |
| Environment and package | |
| Mounting Feature | - |
| Mounting Type | Surface Mount, Right Angle |
| Operating Temperature | -25°C ~ 85°C |
| Thread Size | - |
| Other | |
| Actual Diameter | 0.051" (1.30mm ID), 0.154" (3.90mm OD) |
| Body Color | Black |
| Body Material | - |
| Connector Type | Jack |
| Contact Material | Brass, Copper Alloy |
| Contact Material - Plating | Silver |
| Features | Board Guide |
| Gender | Male |
| Housing Material | Polyamide (PA6T), Nylon 6T |
| Includes | - |
| Industry Recognized Mating Diameter | 1.35mm ID (0.053"), 3.50mm OD (0.138") |
| Ingress Protection | - |
| Insulation Color | - |
| Internal Switch(s) | Single Switch, Normally Closed |
| Manufacturer | Same Sky |
| Material Flammability Rating | UL94 V-0 |
| Mating Length/Depth | - |
| Number of Positions/Contacts | 2 Conductors, 3 Contacts |
| Packaging | Tape & Reel (TR) Cut Tape (CT) Digi-Reel® |
| Part Status | Obsolete |
| Series | - |
| Shielding | Unshielded |
| Termination | Solder |
