PHYCORE-IMX-8M
ActiveDas phyCORE-i.MX 8M System on Module mit i.MX 8M Dual/Quad eignet sich besonders für Multimedia-Anwendungen, Bedieneinheiten und vernetzte Anwendungen.
All alternatives
View full reportTechnical parameters
| Power | |
|---|---|
| Power supply | 3.3 V |
| AC and DC characteristics | |
| Frequency | up to 4x 1.5 GHz |
| Environment and package | |
| Dimensions | 60 mm x 40 mm |
| Temperature range | 0°C to +70°C, -40°C to +85°C |
| Other | |
| Architecture | ARM Cortex-A53 / Cortex-M4F |
| Audio | up to 6x SAI, 1x SPDIF |
| Bit width | Architecture 64-bit, RAM bus connection 32-bit |
| Bluetooth | BLE 4.2 |
| Camera | 2x MIPI CSI-2 |
| Connectors | 501 solder pads, 1.27 mm pitch, Fused Tin Grid Array (FTGA) |
| Display | 1x MIPI DSI, 1x HDMI |
| EEPROM | 4 kB |
| eMMC | 4 GB - 64 GB |
| Ethernet | 1x 10/100/1000 Mbit/s, RGMII optional |
| Graphics | 3D GPU (Vivante GC7000 Lite) |
| I²C | 3x |
| LPDDR4 RAM | 512 MB - 8 GB |
| MMC/SD/SDIO | 1x SDIO |
| Operating system | Linux (Yocto based), Android (by emteria) |
| PCle | 2x PCIe 2.0 |
| Processor | i.MX 8MDual / i.MX 8MQuadLite / i.MX 8MQuad |
| PWM | 4x |
| RTC | Low power, high precision external RTC |
| Security | AES, 3DES, RSA, ECC Ciphers, SHA1/256, TRNG |
| SPI | up to 3x ECSPI, 2x QSPI |
| SPI NOR Flash | 4 MB - 64 MB |
| UART | 4x |
| USB | 2x USB 3.0 OTG |
| Video | 4k Ultra HD, HDR10, Dolby Vision |
| WiFi | 802.11 b/g/n (ac) 2.4 GHz / 5 GHz |
