PHYCORE-IMX-6-UL-ULL
ActiveDas phyCORE-i.MX 6UL ist ein industrietaugliches Embedded SOM mit vollständiger Linux-Implementierung, das zu Serienpreisen unter 20 Euro erhältlich ist.
All alternatives
View full reportTechnical parameters
| Power | |
|---|---|
| Power supply | 3.3 V |
| AC and DC characteristics | |
| Frequency | 528 MHz - 900 MHz |
| Environment and package | |
| Dimensions | 36 mm x 36 mm |
| Temperature range | -40 °C to +85 °C |
| Other | |
| A/D | 2 x 10 Bit |
| Architecture | ARM Cortex-A7 |
| Audio | 3x I²S/SAI |
| Bit width | 32 bit |
| Camera | 1x parallel |
| CAN | 2x |
| DDR3 RAM | 128 MB - 2 GB |
| Display | 24 bit parallel, up to WXGA (1366x768) |
| EEPROM | 4 kB |
| eMMC | 4 GB - 128 GB |
| Ethernet | 2x 10/100 Mbit/s |
| I²C | 4x |
| Keypad | 1x |
| MMC/SD/SDIO | 2x |
| NAND Flash | 128 MB - 2 GB |
| Operating system | Linux (Yocto based), QNX (by BitCtrl) |
| PCB connection | 124 plated half-holes (1 mm pitch) + 35 solder pads |
| Processor | i.MX 6UL G0-G3 / i.MX 6ULL Y0-Y2 |
| PWM | 8x |
| RTC | yes |
| Security | AES, Ciphers, RNG, Tamper, RSA |
| SPI | 4x |
| UART | 8x |
| USB | 2x Host/OTG |
