Panjit International Inc.Taiwan, China
GLASS PASSIVATED JUNCTION TRANSI
All alternatives
View full reportTechnical parameters
Key specs
Reverse standoff voltage8.9 V
Breakdown voltage9.9 V
Clamping voltage16.2 VMax
Peak pulse power400 W
PolarityBidirectional
| Power | |
|---|---|
| Bidirectional Channels | 1 |
| Current - Peak Pulse (10/1000µs) | 26A |
| Power Line Protection | No |
| Power - Peak Pulse | 400W |
| Voltage - Breakdown (Min) | 9.9V |
| Voltage - Clamping (Max) @ Ipp | 16.2V |
| Voltage - Reverse Standoff (Typ) | 8.9V |
| AC and DC characteristics | |
| Capacitance @ Frequency | - |
| Environment and package | |
| Mounting Type | Through Hole |
| Operating Temperature | -65°C~175°C(TJ) |
| Package | Tape & Reel (TR); Cut Tape (CT) |
| Package / Case | DO-204AL, DO-41, Axial |
| Supplier Device Package | DO-41 |
| Other | |
| Applications | General Purpose |
| Base Product Number | P4KE11 |
| Mfr | Panjit International Inc. |
| Product Status | Last Time Buy |
| Series | P4KE |
| Type | Zener |
