View full reportTechnical parameters
| Environment and package | |
|---|---|
| Package | DO-41 |
| Other | |
| IPP(A) | 2.6 |
| IR@VRWM(μA) | 1 |
| PPPM（W） | 400 |
| Status | Active |
| Tj（℃） | -55～+150 |
| Type | Uni |
| VBR_Max(V) | 116.00 |
| VBR_Min(V) | 105.00 |
| VC@IPP(V) | 152 |
| VRWM(V) | 94 |
Documents
DatasheetDatasheet · 249.3 KB · 2026-09-23EnvironmentalEnvironmental · 3.5 MB · 2026-09-23EnvironmentalEnvironmental · 3.4 MB · 2026-09-23EnvironmentalEnvironmental · 1.5 MB · 2026-09-23EnvironmentalEnvironmental · 1.4 MB · 2026-09-23Package DrawingPackage Drawing · 280.3 KB · 2026-09-23
