Analog Devices Inc.United States
IC OPAMP GP 600KHZ LN 15MA 8DIP
All alternatives
View full reportTechnical parameters
Key specs
Supply voltage6 ~ 36 V
Input offset voltage45 µVTyp
Quiescent current1.1 mATyp
Channels1
| Power | |
|---|---|
| Current - Input Bias | 200 pA |
| Current - Output / Channel | 15 mA |
| Current - Supply | 1.1mA |
| Voltage - Supply Span (Max) | 36 V |
| Voltage - Supply Span (Min) | 6 V |
| AC and DC characteristics | |
| Slew Rate | 0.2V/µs |
| Voltage - Input Offset | 45 µV |
| Environment and package | |
| Mounting Type | Through Hole |
| Operating Temperature | -40°C~125°C |
| Package | Tube |
| Package / Case | 8-DIP (0.300", 7.62mm) |
| Supplier Device Package | 8-PDIP |
| Other | |
| Amplifier Type | General Purpose |
| Base Product Number | OP07D |
| Mfr | Analog Devices Inc. |
| Number of Circuits | 1 |
| Output Type | - |
| Product Status | Obsolete |
| Series | - |
