Pulse drive is used in a control motor, for example, so reflected waves resulting from impedance mismatching between the cable, motor, and control section are superimposed on the signal, resulting in cools which become high voltage noise cools.
All alternatives
View full reportTechnical parameters
| Environment and package | |
|---|---|
| Conductor size (mm^2) (*2) | Insulation Outer diameter(mm) |
| Operating ambient temperature | 0°C～50°C |
| Rated temperature and voltage | 60°C,600V |
| Storage ambient temperature | -30°C～60°C |
| Other | |
| Cable type | Product code |
| Environmental compliance | RoHS compliant |
| Fixed part | VCT-SYM2SQ |
| Official series page | https://www.okidensen.co.jp/en/prod/cool/vct-sym.html |
| Safety standards | Electrical Appliances and Materials Safety Act (PSE) |
| VCT-SYM3.5SQ | 3.5 |
| VCT-SYM5.5SQ | 5.5 |
| VCT-SYM8SQ(*1) | 8 |
