View full reportTechnical parameters
| Power | |
|---|---|
| Current Rating (Amps) | 1.9A |
| Power (Watts) | 22 W |
| Voltage Range | - |
| Voltage - Rated | 12VDC |
| AC and DC characteristics | |
| Noise | 60.0dB |
| Environment and package | |
| Lifetime @ Temp. | 50000 Hrs @ 40°C |
| Operating Temperature | 14 ~ 158°F (-10 ~ 70°C) |
| Size / Dimension | Square - 80mm L x 80mm H |
| Other | |
| Air Flow | 112.0 CFM (3.14m³/min) |
| Approval Agency | cURus, TUV |
| Base Product Number | OD8038 |
| Bearing Type | Ball |
| Fan Type | Tubeaxial |
| Features | Auto Restart |
| Ingress Protection | - |
| Material - Blade | Polybutylene Terephthalate (PBT), Fiberglass Reinforced |
| Material - Frame | Polybutylene Terephthalate (PBT), Fiberglass Reinforced |
| Mfr | Orion Fans |
| Packaging | Bulk |
| Part Status | Active |
| RPM | 7100 RPM |
| Series | OD8038 VA |
| Static Pressure | 1.100 in H2O (274.0 Pa) |
| Termination | 2 Wire Leads |
| Weight | - |
| Width | 38.00mm |
