AC/DC CONVERTER 12V 100W
All alternatives
View full reportTechnical parameters
Key specs
Input voltage85 ~ 264 V
Output voltage12 V
Output current8.3 AMax
Power100 WMax
Outputs1
| Power | |
|---|---|
| Current - Output 1 | 8.3 A |
| Power (Watts) | 100W (120W Forced Air) |
| Voltage - Input | 85 ~ 264 VAC |
| Voltage - Output 1 | 12V |
| Voltage - Output 2 | - |
| Voltage - Output 3 | - |
| Voltage - Output 4 | - |
| Voltage - Output 6 | - |
| Environment and package | |
| Mounting Type | Chassis Mount |
| Operating Temperature | -20°C~70°C(WithDerating) |
| Package | Bulk |
| Size / Dimension | 4.50" L x 2.50" W x 1.10" H (114.3mm x 63.1mm x 28.5mm) |
| Other | |
| Applications | Medical |
| Approval Agency | CB, CE, cTUVus |
| Base Product Number | MVA100012 |
| Efficiency | 90% |
| Features | Universal Input |
| Mfr | Inventus Power |
| Minimum Load Required | No |
| Number of Outputs | 1 |
| Product Status | Obsolete |
| Series | MVA100 (100W) |
| Type | Open Frame |
