View full reportTechnical parameters
| Environment and package | |
|---|---|
| Mounting Feature | Flange |
| Mounting Type | Panel Mount |
| Operating Temperature | -65°C ~ 175°C |
| Shell Size - Insert | 24-35 |
| Shell Size, MIL | - |
| Other | |
| Base Product Number | MS27472T24B |
| Connector Type | Receptacle Housing |
| Fastening Type | Bayonet Lock |
| Features | - |
| Ingress Protection | - |
| Manufacturer | Conesys |
| Material Flammability Rating | - |
| Number of Positions | 128 |
| Orientation | N (Normal) |
| Packaging | Box |
| Part Status | Active |
| Primary Material | Metal |
| Series | Military, MIL-DTL-38999 Series II |
| Shell Finish | Olive Drab Cadmium |
| Shell Material | Aluminum |
| Shielding | Shielded |
| Type | For Male Pins |
Documents
No documents are linked to this part yet.
