View full reportTechnical parameters
Key specs
Rated current4 A
Rated voltage250 V
Response timeFast
Breaking capacity40 A
| Power | |
|---|---|
| Breaking Capacity @ Rated Voltage | 40A |
| Current Rating (Amps) | 4 A |
| Voltage Rating - AC | 250 V |
| Environment and package | |
| Mounting Type | Through Hole |
| Operating Temperature | -55°C ~ 125°C |
| Package / Case | Radial, Can, Vertical |
| Size / Dimension | 0.329" Dia x 0.303" H (8.35mm x 7.70mm) |
| Other | |
| Approval Agency | AEC-Q200, CE, CSA, cULus, PSE, SEMKO, VDE |
| Color | - |
| DC Cold Resistance | 0.011 Ohms |
| Fuse Type | Board Mount (Cartridge Style Excluded) |
| Melting I²t | 8.0 |
| Mfr | Bel Fuse Inc. |
| Packaging | Tape & Box (TB) |
| Part Status | Obsolete |
| Response Time | Fast Blow |
| Series | MRF |
