View full reportTechnical parameters
| Power | |
|---|---|
| Current - Reverse Leakage @ Vr | 3 µA @ 6.5 V |
| Power - Max | 200 mW |
| Voltage - Forward (Vf) (Max) @ If | 900 mV @ 10 mA |
| Voltage - Zener (Nom) (Vz) | 8.2 V |
| AC and DC characteristics | |
| Impedance (Max) (Zzt) | 8 Ohms |
| Environment and package | |
| Mounting Type | Surface Mount |
| Operating Temperature | -65°C ~ 150°C |
| Package / Case | 6-TSSOP, SC-88, SOT-363 |
| Supplier Device Package | SOT-363 |
| Other | |
| Base Product Number | MMBZ5237 |
| Configuration | 2 Independent |
| Manufacturer | Diodes Incorporated |
| Packaging | Tape & Reel (TR) Cut Tape (CT) Digi-Reel® |
| Part Status | Active |
| Series | - |
| Tolerance | ±5% |
Documents
No documents are linked to this part yet.
