Micrel Inc.United States
IC REG LINEAR DUAL 150MA LDO
All alternatives
View full reportTechnical parameters
Key specs
Output voltage2.85 V
Output current150 mAMax
Input voltage≤ 5.5 V
Dropout voltage100 mVMax · 150mA，150mA
Quiescent current120 µATyp
| Power | |
|---|---|
| Current - Output | 150mA, 150mA |
| Current - Quiescent (Iq) | 120 µA |
| Current - Supply (Max) | 190 µA |
| Voltage Dropout (Max) | 0.1V @ 150mA, 0.1V @ 150mA |
| Voltage - Input (Max) | 5.5V |
| Voltage - Output (Max) | - |
| Voltage - Output (Min/Fixed) | 2.85V, 3.3V |
| AC and DC characteristics | |
| PSRR | 70dB ~ 65dB (1kHz ~ 20kHz) |
| Environment and package | |
| Mounting Type | Surface Mount |
| Operating Temperature | -40°C ~ 125°C |
| Package / Case | 8-VFDFN Exposed Pad, 8-MLF® |
| Supplier Device Package | 8-MLF® (2x2) |
| Other | |
| Control Features | Enable |
| Mfr | Micrel Inc. |
| Number of Regulators | 2 |
| Output Configuration | Positive |
| Output Type | Fixed |
| Packaging | Bulk |
| Part Status | Active |
| Protection Features | Over Current, Over Temperature |
| Series | - |
