View full reportTechnical parameters
| Power | |
|---|---|
| Power Level | 50mW |
| Voltage - Isolation | 500VRMS @ 30 Seconds |
| AC and DC characteristics | |
| Frequency Range | 300Hz ~ 100kHz |
| Frequency Response | ±2dB |
| Impedance - Primary (Ohms) | 500 |
| Impedance - Secondary (Ohms) | 50 |
| Environment and package | |
| Height - Seated (Max) | 0.465" (11.80mm) |
| Mounting Type | Through Hole |
| Operating Temperature | -20°C~85°C |
| Package | Tube |
| Size / Dimension | 0.409" L x 0.310" W (10.40mm x 7.87mm) |
| Other | |
| Approval Agency | - |
| DC Resistance (DCR) - Primary | 55Ohm |
| DC Resistance (DCR) - Secondary | 8Ohm |
| Insertion Loss | - |
| Mfr | Tamura |
| Product Status | Active |
| Return Loss | - |
| Series | MET |
| Termination Style | PC Pin |
| Transformer Type | Data/Voice Coupling |
| Turns Ratio - Primary:Secondary | 3.16:1 |
| Weight | - |
