View full reportTechnical parameters
| Power | |
|---|---|
| Current - Max | 4 x 700mA |
| Current - Test | 4 x 350mA |
| Flux @ 25°C, Current - Test | 400lm (370lm ~ 430lm) |
| Flux @ 85°C, Current - Test | - |
| Lumens/Watt @ Current - Test | 92 lm/W |
| Voltage - Forward (Vf) (Typ) | 3.1V |
| Environment and package | |
| Height - Seated (Max) | 0.181" (4.60mm) |
| Mounting Type | Surface Mount |
| Package / Case | 8-SMD, Gull Wing Exposed Pad |
| Size / Dimension | 0.276" L x 0.295" W (7.00mm x 7.50mm) |
| Supplier Device Package | - |
| Thermal Resistance of Package | 3°C/W |
| Other | |
| Base Product Number | MCE4WT |
| CCT (K) | 4750K |
| Color | White, Neutral |
| CRI (Color Rendering Index) | 75 (Typ) |
| Mfr | CreeLED, Inc. |
| Packaging | Tape & Reel (TR) |
| Part Status | Obsolete |
| Series | XLamp® MC-E |
| Viewing Angle | 110° |
