View full reportTechnical parameters
| Power | |
|---|---|
| Current Rating (Amps) | 2A (AC) |
| Voltage Rating | 230VAC |
| Voltage - Supply | - |
| Environment and package | |
| Conduit Thread Size | - |
| Operating Temperature | -10°C~55°C |
| Package | Bulk |
| Other | |
| Actuator Type | Non-Contact |
| Approval Agency | CE, cULus |
| Base Product Number | MA-16AP |
| Circuit | DPST-NO/NC |
| Features | - |
| Holding Force | - |
| Ingress Protection | IP67 - Dust Tight, Waterproof |
| Mfr | Omron Automation and Safety |
| Must Operate | 7 ~ 12mm |
| Must Release | 12 ~ 25mm |
| Product Status | Active |
| Series | MA-STI |
| Termination Style | Cable Leads |
| Type | Magnetic |
