ITT Cannon, LLCUnited States
CONN DSUB PLUG 9POS SOLDER
All alternatives
View full reportTechnical parameters
Key specs
Positions9
Rows2
GenderMale
Current rating3 AMax
| Power | |
|---|---|
| Current Rating (Amps) | 3A |
| Voltage Rating | - |
| Environment and package | |
| Mounting Type | Free Hanging (In-Line) |
| Operating Temperature | -55°C ~ 125°C |
| Package | Bulk |
| Shell Size, Connector Layout | 0.050 Pitch x 0.043 Row to Row |
| Other | |
| Color | - |
| Connector Style | D-Type, Micro-D |
| Connector Type | Plug, Male Pins |
| Contact Finish | Gold |
| Contact Finish Thickness | 50.0µin (1.27µm) |
| Contact Type | Signal |
| Dielectric Material | Liquid Crystal Polymer (LCP) |
| Features | - |
| Flange Feature | Housing/Shell (Unthreaded) |
| Ingress Protection | - |
| Mfr | ITT Cannon, LLC |
| Number of Positions | 9 |
| Number of Rows | 2 |
| Product Status | Active |
| Series | 83513-Style Micro D Metal Shell (MDM) |
| Shell Material, Finish | Aluminum, Nickel Plated, Electroless |
| Termination | Solder Cup |
Documents
No documents are linked to this part yet.
