Lite-On Inc.Taiwan, China
SENSOR PHOTO 940NM SIDE VIEW RAD
All alternatives
View full reportTechnical parameters
| Power | |
|---|---|
| Current - Collector (Ic) (Max) | 2.4 mA |
| Current - Dark (Id) (Max) | 100 nA |
| Power - Max | 100 mW |
| Voltage - Collector Emitter Breakdown (Max) | 30 V |
| Environment and package | |
| Mounting Type | Through Hole |
| Operating Temperature | -40°C~85°C(TA) |
| Package | Bulk |
| Package / Case | Radial |
| Other | |
| Mfr | Lite-On Inc. |
| Orientation | Side View |
| Product Status | Active |
| Series | - |
| Viewing Angle | 70° |
| Wavelength | 940nm |
