Linearin(先积集成)China
All alternatives
View full reportTechnical parameters
Key specs
Quiescent current700 µATyp
Channels1
| Power | |
|---|---|
| 供电电压 | 6.0V~44V |
| 通道数 | 1 |
| 静态电流 | 700μA |
| AC and DC characteristics | |
| 共模抑制比 | 114 |
| 压摆率 | 3V/μs |
| 噪声密度 | 14nV/√Hz |
| 增益带宽 | 4.5MHz |
| 最大失调电压 | 0.025mV |
| 电压噪声 | 0.32μVP-P |
| 电源抑制比 | 123 |
| Environment and package | |
| 封装 | SO8 |
| 温度漂移 | 0.2µV/℃ |
| Other | |
| 轨至轨 | RRIO |
Documents
No documents are linked to this part yet.
