Bel Fuse Inc.United States
Cassettes & Subracks
All alternatives
View full reportTechnical parameters
Key specs
Outputs1
| Power | |
|---|---|
| Input Voltage Range (VAC) | 85 ~ 255 |
| Output Current (A) | 10 |
| Output Voltage (VDC) | 54.5 |
| Power (W) | 500 |
| Environment and package | |
| Mounting Type | Chassis Mount |
| Operating Temperature Range (ºC) | -25 ~ +71 |
| Package | 3U / 28HP cassette |
| RoHS Compliant | Yes |
| Other | |
| Brand | Melcher |
| Cooling Type | Convection |
| Market | Railway |
| Number of Outputs | 1 |
| Options | Case with small cooling plate, Cell voltage selector switch |
| Safety Approvals | CB, CE, CSA, Nemko |
| Safety Standards | 62368 |
