Mechatronics Fan GroupUnited States
FAN AXIAL 172X150X51MM 115VAC
All alternatives
View full reportTechnical parameters
| Power | |
|---|---|
| Current Rating (Amps) | - |
| Power (Watts) | 10.00W |
| Voltage Range | 90 ~ 264VAC |
| Voltage - Rated | 115VAC |
| AC and DC characteristics | |
| Noise | 50.0dB(A) |
| Environment and package | |
| Lifetime @ Temp. | - |
| Operating Temperature | -40~158°F(-40~70°C) |
| Package | Bulk |
| Size / Dimension | Rectangular/Rounded - 172mm L x 150mm H |
| Other | |
| Air Flow | 210.0 CFM (5.88m³/min) |
| Approval Agency | - |
| Bearing Type | Ball |
| Fan Type | Tubeaxial |
| Features | Electronic Commutation (EC) |
| Ingress Protection | - |
| Material - Blade | Plastic |
| Material - Frame | Magnesium |
| Mfr | Mechatronics Fan Group |
| Product Status | Obsolete |
| RPM | 2800 RPM |
| Series | LPC15P |
| Static Pressure | 0.480 in H2O (119.6 Pa) |
| Termination | 2 Terminals |
| Weight | 1.5 lbs (680.4 g) |
| Width | 51.00mm |
Documents
No documents are linked to this part yet.
