Mechatronics Fan GroupUnited States
FAN AXIAL 120X38MM 90-264VAC EC
All alternatives
View full reportTechnical parameters
| Power | |
|---|---|
| Current Rating (Amps) | - |
| Power (Watts) | 6.00W |
| Voltage Range | 90 ~ 264VAC |
| Voltage - Rated | 90 ~ 264VAC |
| AC and DC characteristics | |
| Noise | 43.0dB(A) |
| Environment and package | |
| Lifetime @ Temp. | - |
| Operating Temperature | -40 ~ 158°F (-40 ~ 70°C) |
| Package | Bulk |
| Size / Dimension | Square - 120mm L x 120mm H |
| Other | |
| Air Flow | 84.0 CFM (2.35m³/min) |
| Approval Agency | - |
| Bearing Type | Ball |
| Fan Type | Tubeaxial |
| Features | Electronic Commutation (EC) |
| Ingress Protection | - |
| Material - Blade | Plastic |
| Material - Frame | Magnesium |
| Mfr | Mechatronics Fan Group |
| Product Status | Obsolete |
| RPM | 2800 RPM |
| Series | LPC12A |
| Static Pressure | 0.280 in H2O (69.7 Pa) |
| Termination | 2 Terminals |
| Weight | 0.816 lb (370.13 g) |
| Width | 38.00mm |
Documents
No documents are linked to this part yet.
