LM-20M18G-100W-15DBM

Quantic PMI Model LM-20M18G-100W-15DBM is an RF Limiter that operates in the frequency range of 0.02 to 18 GHz that can handle up to 100 W CW more than 0.02 to 18 GHz, for all temperatures (-55 °C to +85 °C). The energy input provides leaks of 15 dBm maximum. This model has a low insertion loss of 2.6 dB and a maximum recovery time of 100 ns. Model has 0.90" x 0.38" x 0.38" compact housing with SMA connectors.
