EPtronics, Inc.United States
LED DRIVER AC/DC CC 48-142V 1.4A
All alternatives
View full reportTechnical parameters
| Power | |
|---|---|
| Current - Output (Max) | 1.4A |
| Power (Watts) | 200 W |
| Voltage - Input (Max) | 305VAC |
| Voltage - Input (Min) | 90VAC |
| Voltage - Isolation | 3.75 kV |
| Voltage - Output | 48 ~ 142V |
| Environment and package | |
| Mounting Type | Chassis Mount |
| Operating Temperature | -30°C~60°C |
| Package | Bulk |
| Size / Dimension | 8.92" L x 2.33" W x 1.47" H (226.6mm x 59.2mm x 37.3mm) |
| Other | |
| Approval Agency | CE, cUL, cURus, FCC |
| Base Product Number | LD200W |
| Dimming | Analog, PWM |
| Efficiency | 91% |
| Features | OCP, OVP, SCP |
| Mfr | EPtronics, Inc. |
| Number of Outputs | 1 |
| Product Status | Active |
| Ratings | IP66 |
| Series | LD200W |
| Termination Style | Wire Leads |
| Topology | AC DC Converter |
| Type | Constant Current |
