View full reportTechnical parameters
| Environment and package | |
|---|---|
| Mounting Type | Free Hanging (In-Line) |
| Stud/Tab Size | 3/8 Stud |
| Other | |
| Color | Brown |
| Contact Finish | Electro-Tin |
| Contact Material | Copper |
| Diameter - Barrel ID | 0.310" (7.87mm) |
| Diameter - Barrel OD | 0.420" (10.67mm) |
| Diameter - Ring ID | 0.410" (10.41mm) |
| Features | - |
| Insulation | Non-Insulated |
| Length - Overall | 1.660" (42.16mm) |
| Manufacturer | Panduit Corp |
| Packaging | Bulk |
| Part Status | Obsolete |
| Series | Pan-Lug™ |
| Tab Thickness | 0.100" (2.54mm) |
| Terminal Style | Single Stud Hole |
| Terminal Type | Rectangular Tongue |
| Termination | Crimp, Barrel |
| Width - Outer Edges | 0.660" (16.76mm) |
| Wire Gauge | 2 AWG |
