View full reportTechnical parameters
| Environment and package | |
|---|---|
| Mounting Type | Free Hanging (In-Line) |
| Stud/Tab Size | 3/8 Stud |
| Other | |
| Base Product Number | LAMA500 |
| Color | - |
| Contact Finish | Tin |
| Contact Material | Aluminum |
| Diameter - Barrel ID | - |
| Diameter - Barrel OD | - |
| Diameter - Ring ID | - |
| Features | With Screw |
| Insulation | Non-Insulated |
| Length - Overall | 2.810" (71.37mm) |
| Manufacturer | Panduit Corp |
| Packaging | Bulk |
| Part Status | Obsolete |
| Series | LAMA |
| Tab Thickness | 0.310" (7.87mm) |
| Terminal Style | Single Stud Hole |
| Terminal Type | Lug, Grounding |
| Termination | Screw |
| Width - Outer Edges | 1.500" (38.10mm) |
| Wire Gauge | 500MCM (kcmil)-4 AWG |
Documents
No documents are linked to this part yet.
