View full reportTechnical parameters
| Environment and package | |
|---|---|
| Mounting Type | Free Hanging (In-Line) |
| Stud/Tab Size | 3/16 Stud |
| Other | |
| Base Product Number | LAA4 |
| Color | - |
| Contact Finish | Tin |
| Contact Material | Aluminum |
| Diameter - Barrel ID | 0.260" (6.60mm) |
| Diameter - Barrel OD | 0.470" (11.94mm) |
| Diameter - Ring ID | - |
| Features | Gel Filled |
| Insulation | Non-Insulated |
| Length - Overall | 2.230" (56.64mm) |
| Manufacturer | Panduit Corp |
| Packaging | Bulk |
| Part Status | Discontinued at Digi-Key |
| Series | - |
| Tab Thickness | 0.160" (4.06mm) |
| Terminal Style | Single Stud Hole |
| Terminal Type | Rectangular Tongue |
| Termination | Crimp, Barrel |
| Width - Outer Edges | 0.690" (17.53mm) |
| Wire Gauge | 4 AWG |
Documents
No documents are linked to this part yet.
