KR DMLQ31.23-HYKY-26-J3T3-350-R18-Z

LED SYNIOS RED 621NM 2SMD

All alternatives

Power
Current - Max	500mA
Current - Test	350mA
Lumens/Watt @ Current - Test	80 lm/W
Voltage - Forward (Vf) (Typ)	2.32V
Environment and package
Height - Seated (Max)	0.028" (0.70mm)
Luminous Flux @ Current/Temperature	65lm(33lm~97lm)
Mounting Type	Surface Mount
Package	Tape & Reel (TR); Cut Tape (CT); Digi-Reel®
Package / Case	1108 (2720 Metric)
Size / Dimension	0.108" L x 0.079" W (2.75mm x 2.00mm)
Supplier Device Package	2-SMD
Temperature - Test	25°C
Other
Base Product Number	KRDMLQ31.23
Color	Red
Mfr	OSRAM Opto (ams OSRAM)
Product Status	Last Time Buy
Series	SYNIOS
Viewing Angle	120°
Wavelength	621nm (Typ)

No documents are linked to this part yet.
