View full reportTechnical parameters
| Power | |
|---|---|
| Current Rating (Amps) | 0.130A |
| Power (Watts) | 600 mW |
| Voltage Range | 4 ~ 6VDC |
| Voltage - Rated | 5VDC |
| AC and DC characteristics | |
| Noise | 29.0dB(A) |
| Environment and package | |
| Lifetime @ Temp. | - |
| Operating Temperature | 14 ~ 158°F (-10 ~ 70°C) |
| Size / Dimension | Square - 50mm L x 50mm H |
| Other | |
| Air Flow | 8.0 CFM (0.224m³/min) |
| Approval Agency | cUR, UL |
| Bearing Type | Sleeve |
| Fan Type | Tubeaxial |
| Features | - |
| Ingress Protection | - |
| Material - Blade | Polybutylene Terephthalate (PBT) |
| Material - Frame | Polybutylene Terephthalate (PBT) |
| Mfr | Sunon Fans |
| Part Status | Obsolete |
| RPM | 4300 RPM |
| Series | KDE |
| Static Pressure | 0.090 in H2O (22.4 Pa) |
| Termination | 2 Wire Leads |
| Weight | 0.053 lb (24.04 g) |
| Width | 10.00mm |
Documents
No documents are linked to this part yet.
