Lumissil MicrosystemsUnited States
IC LED DRV RGLTR PWM 750MA 14DFN
All alternatives
View full reportTechnical parameters
Key specs
TopologyBoost
Outputs2
Output current per channel750 mAMax
Input voltage2.7 ~ 5.5 V
| Power | |
|---|---|
| Current - Output / Channel | 750mA (Flash) |
| Voltage - Output | - |
| Voltage - Supply (Max) | 5.5V |
| Voltage - Supply (Min) | 2.7V |
| AC and DC characteristics | |
| Frequency | 2MHz |
| Environment and package | |
| Mounting Type | Surface Mount |
| Operating Temperature | -40°C~85°C(TA) |
| Package | Tape & Reel (TR); Cut Tape (CT); Digi-Reel® |
| Package / Case | 14-WFDFN Exposed Pad |
| Supplier Device Package | 14-DFN (3x2) |
| Other | |
| Applications | Backlight, Camera Flash |
| Base Product Number | IS31BL3233 |
| Dimming | PWM |
| Internal Switch(s) | Yes |
| Mfr | Lumissil Microsystems |
| Number of Outputs | 2 |
| Product Status | Obsolete |
| Series | - |
| Topology | Step-Up (Boost) |
| Type | DC DC Regulator |
Documents
No documents are linked to this part yet.
