IRLML6302TRPBF-1 is a P-channel power MOSFETs with VDS max: -20 V, RDS (on) max: 600 mOhm, Package: SOT-23, Technology: IR MOSFET™, Polarity: P
All alternatives
View full reportTechnical parameters
Key specs
Gate threshold voltage-1.1 VMax
| Environment and package | |
|---|---|
| Moisture Sensitivity Level | 1 |
| Mounting | SMD |
| Package | SOT-23 |
| Other | |
| ID (@25°C) max | -0.78 A |
| Polarity | P |
| Ptot (@ TA=25°C) max | 4.3 W |
| Qgd | 1 nC |
| QG (typ @4.5V) | 2.4 nC |
| RDS (on) (@4.5V) max | 600 mΩ |
| RthJA max | 230 K/W |
| Special Features | Small Signal |
| Tj max | 150 °C |
| VDS max | -20 V |
| VGS max | 12 V |
| VGS(th) | -1.1 V |
| VGS(th) range | -0.7 V to -1.5 V |
