IRF7380PBF-1 is a N-channel power MOSFETs with VDS max: 80 V, RDS (on) max: 73 mOhm, Package: SO-8, Technology: IR MOSFET™, ID max: 3.6 A
All alternatives
View full reportTechnical parameters
Key specs
Gate threshold voltage3 VMax
| Environment and package | |
|---|---|
| Moisture Sensitivity Level | 1 |
| Package | SO-8 |
| Other | |
| ID (@25°C) max | 3.6 A |
| Polarity | N+N, N+N |
| Ptot (@ TA=25°C) max | 2 W |
| Qgd (typ) | 4.5 nC |
| QG (typ @10V) | 15 nC |
| RDS (on) (@10V) max | 73 mΩ |
| RthJA max | 62.5 K/W |
| Tj max | 150 °C |
| VDS max | 80 V |
| VGS max | 20 V |
| VGS(th) | 3 V |
| VGS(th) range | 2 V to 4 V |
