IO Audio TechnologiesUnited States
CAT5E STP COPPER STRANDED CABLE
All alternatives
View full reportTechnical parameters
| Environment and package | |
|---|---|
| Operating Temperature | -20°C~75°C |
| Package | Bulk |
| Other | |
| Cable Type | Multi-Pair, Cat5e |
| Conductor Insulation | High Density Polyethylene (HDPE) |
| Conductor Material | Copper, Bare |
| Conductor Strand | - |
| Features | Drain Wire |
| Jacket Color | Gray |
| Jacket (Insulation) Diameter | 0.307" (7.80mm) |
| Jacket (Insulation) Material | Poly-Vinyl Chloride (PVC) |
| Jacket (Insulation) Thickness | 0.0236" (0.600mm) |
| Length | 1000.0' (304.8m) |
| Mfr | IO Audio Technologies |
| Number of Conductors | 8 (4 Pair Twisted) |
| Product Status | Obsolete |
| Ratings | UL Style CMR |
| Series | - |
| Shield Coverage | - |
| Shield Material | Aluminum |
| Shield Type | Foil |
| Usage | - |
| Wire Gauge | 26 AWG |
Documents
No documents are linked to this part yet.
