InoluxUnited States
LED RGB TOP VIEW SMD
All alternatives
View full reportTechnical parameters
Key specs
ColorMulticolor
Wavelength621 nm
Forward voltage3.4 VMax
Test current10 mA
Luminous intensity17 ~ 85 mcd
| Power | |
|---|---|
| Current - Test | 10mA Red, 10mA Green, 10mA Blue |
| Voltage - Forward (Vf) (Typ) | 2.4V Red, 3.4V Green, 3.4V Blue |
| Environment and package | |
| Height (Max) | 0.75mm |
| Lens Size | 1.00mm |
| Mounting Type | Surface Mount |
| Package | Tape & Reel (TR); Cut Tape (CT); Digi-Reel® |
| Package / Case | 0404 (1010 Metric) |
| Size / Dimension | 1.00mm L x 1.00mm W |
| Supplier Device Package | SMD |
| Other | |
| Base Product Number | IN-B101 |
| Color | Red, Green, Blue (RGB) |
| Configuration | Common Anode |
| Features | - |
| Lens Color | - |
| Lens Style | Square with Flat Top |
| Lens Transparency | - |
| Mfr | Inolux |
| Millicandela Rating | 58mcd Red, 85mcd Green, 17mcd Blue |
| Product Status | Last Time Buy |
| Series | - |
| Viewing Angle | 140° |
| Wavelength - Dominant | 621nm Red, 531nm Green, 470nm Blue |
| Wavelength - Peak | 629nm Red, 520nm Green, 480nm Blue |
