View full reportTechnical parameters
| Diameter - Inside | 0.695" (17.65mm) |
| Diameter - Outside | 0.875" (22.23mm) |
| End Style | Closed |
| Finish | Zinc |
| Free Length | 2.000" (50.80mm) |
| Manufacturer | Century Spring Corp |
| Material | Spring Steel |
| Packaging | Box |
| Part Status | Active |
| Rate | 32.0 lbs/in |
| Series | - |
| Type | Compression |
| Wire Diameter | 0.090" (2.29mm) |
Documents
No documents are linked to this part yet.
