IHVA200-A3D24V-BF
TE ConnectivitySwitzerland

IHVA200-A3D24V-BF

ObsoleteContactors (Electromechanical)

RELAY CONTACTOR SPST 200A 24V

See alternativesAsk AI FAE

All alternatives

View full report

Technical parameters

Power
Coil Current208.7 mA
Coil Power5W
Coil Voltage24VDC
Contact Rating (Current)200 A
Must Operate Voltage18 VDC
Must Release Voltage2 VDC
Switching Voltage1500VDC - Max
Environment and package
Mounting TypeChassis Mount
Operating Temperature-40°C~85°C
PackageBox
Other
Coil Resistance115Ohms
Contact FormSPST-NO (DM) (1 Form X)
Contact MaterialSilver Alloy
Features-
MfrTE Connectivity Potter & Brumfield Relays
Operate Time65 ms
Product StatusObsolete
Release Time20 ms
SeriesIHVA200
Termination StyleStud
