View full reportTechnical parameters
| Environment and package | |
|---|---|
| Package | SOT-23-3L |
| Other | |
| ID(A) | -5.7 |
| N/P | P |
| Process | Trench |
| Rdson_-4.5V(mΩ) Max | 34 |
| Rdson_-4.5V(mΩ) Typ | 25.8 |
| Vdss(V) | -20 |
| Vgs(V) | ±12 |
| Vth (V) Max. | -1 |
| Vth (V) Min. | -0.45 |
| Vth (V) Typ. | -0.7 |
Documents
No documents are linked to this part yet.
