HS400 25R J
OhmiteUnited States

HS400 25R J

ActiveChassis Mount Resistors

400 WATT CHASSIS MOUNT

See alternativesAsk AI FAE

All alternatives

View full report

Technical parameters

Key specs

Resistance25 Ω
Tolerance5 %
Power400 W
Temperature coefficient150 ppm/°C
Power
Power (Watts)400W
Environment and package
Height - Seated (Max)1.181" (30.00mm)
Mounting FeatureFlanges
Operating Temperature-
PackageBox
Package / CaseRadial, Rectangular Case
Size / Dimension7.165" L x 2.185" W (182.00mm x 55.50mm)
Temperature Coefficient±150ppm/°C
Other
Coating, Housing TypeAluminum
CompositionWirewound
Failure Rate-
Features-
Lead StyleWire Leads
MfrOhmite
Product StatusActive
Resistance25 Ohms
SeriesARCOL, HS
Tolerance±5%

Documents

No documents are linked to this part yet.
