View full reportTechnical parameters
| Power | |
|---|---|
| Current - Max | 1.3A |
| Current - Test | 350mA |
| Flux @ 25°C, Current - Test | - |
| Flux @ 85°C, Current - Test | 117lm (104lm ~ 130lm) |
| Lumens/Watt @ Current - Test | 117 lm/W |
| Voltage - Forward (Vf) (Typ) | 2.85V |
| Environment and package | |
| Height - Seated (Max) | 0.062" (1.58mm) |
| Mounting Type | Surface Mount |
| Package | Tape & Reel (TR) |
| Package / Case | 1212 (3030 Metric) |
| Size / Dimension | 0.118" L x 0.118" W (3.00mm x 3.00mm) |
| Supplier Device Package | SMD |
| Thermal Resistance of Package | 5.25°C/W |
| Other | |
| CCT (K) | 2700K |
| Color | White, Warm |
| CRI (Color Rendering Index) | 80 |
| Mfr | OSRAM Opto (ams OSRAM) |
| Product Status | Discontinued at Digi-Key |
| Series | OSLON® SSL 150 |
| Viewing Angle | 150° |
